Description

The Sunsynk 12kW SYNK10-SG04LP3 inverter represents cutting-edge technology in the field of solar energy conversion. With its robust construction and advanced features, this inverter is designed to meet the demanding needs of residential, commercial, and industrial applications.

At the heart of the Sunsynk inverter is a powerful multi-core processor that ensures high reliability and fast response times. This enables seamless operation and precise control over energy flow, maximising the efficiency of your solar energy system.

One of the standout features of the Sunsynk inverter is its versatility. It offers multiple operating modes, including grid-tie, hybrid, and off-grid, allowing you to adapt to different energy scenarios with ease. Whether you’re looking to reduce your electricity bills, achieve energy independence, or simply contribute to a greener future, the Sunsynk inverter has you covered.

In addition to its advanced functionality, the Sunsynk inverter prioritises safety and reliability. It comes equipped with a comprehensive set of protection mechanisms, including PV arc fault detection, anti-islanding protection, and output overcurrent protection, ensuring the safety of both your system and your property.

Furthermore, the Sunsynk inverter is designed for ease of installation and maintenance. Its wall-mounted installation style and compact cabinet size make it suitable for a variety of installation environments, while its IP65 protection rating ensures durability and longevity, even in harsh outdoor conditions.

Backed by a generous 5-year warranty, the Sunsynk 12kW SYNK10-SG04LP3 inverter is not just a product—it’s a reliable investment in the future of your energy needs. Whether you’re a homeowner looking to harness the power of solar energy or a business owner seeking to optimise your energy usage, the Sunsynk inverter delivers unmatched performance and peace of mind.

Product Specs Bullet Point List:

• Model: SYNK-12K-SG04LP3
• Battery Input Date:
  • Battery Type: Lead-acid or Li-Ion
  • Battery Voltage Range: 40Vd.c ~ 60Vd.c
  • Max. Charging/Discharging Current: 240Ad.c (max.)
  • Charging Curve: 3 Stages / Equalization
  • External Temperature Sensor: Yes
  • Charging Strategy for Li-Ion Battery: Self-adaption to BMS
• PV String Input Data:
  • Max. DC Input Power: 15600W
  • PV Input Voltage: 550Vd.c (160Vd.c ~ 800Vd.c)
  • MPPT Range: 200Vd.c ~ 650Vd.c
  • Start-up Voltage: 160V
  • PV Input Current: 26Ad.c + 13Ad.c
  • Max. PV Isc: 34Ad.c + 17Ad.c
  • No. of MPPT Trackers: 2
  • No. of Strings Per MPPT Tracker: 2+1
• AC Output Data:
  • Rated AC Output and UPS Power: 12000W
  • Max. AC Output Power: 13200W
  • Peak Power (off grid): 2 times of rated power, 10s
  • AC Output Rated Current: 18.2/17.4A
  • Max. AC Current: 20/19.1A
  • Max. Three-phase Unbalanced Output Current: 27.3/26.1A
  • Max. Output Short Circuit Current: 75A
  • Max. Continuous AC Passthrough: 45A
  • Output Frequency and Voltage: 50/60Hz;3L/N/PE 220/380, 230/400Vac (Three phase)
  • Grid Type: Three phase
  • Total Harmonic Distortion (THD): <3% (of nominal power)
  • DC current injection: <0.5% ln
• Efficiency:
  • Max. Efficiency: 97.60%
  • Euro Efficiency: 97.00%
  • MPPT Efficiency: >99%
• Protection:
  • Integrated PV Arc Fault Detection
  • PV Input Lightning Protection
  • Anti-islanding Protection
  • PV String Input Reverse Polarity Protection
  • Insulation Resistor Detection
  • Residual Current Monitoring Unit
  • Output Over Current Protection
  • Output Shorted Protection
  • Surge Protection: DC Type III / AC Type III
  • Over Voltage Category: DC Type II / AC Type III
• Certifications and Standards:
  • Grid Regulation: EN 50549-1, AS-NZS 4777.2, NRS 097-2-1
  • EMC/Safety Regulation: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
• General Data:
  • Operating Temperature Range: -40~60 ºC, >45 ºC Derating
  • Cooling: Smart cooling
  • Noise: ≤45 dB
  • Communication with BMS: RS485; CAN
  • Net Weight: 38.5kg
  • Gross Weight: 47.5kg
  • Cabinet size: 422W×702H×281D (Excluding connectors and brackets)
  • Protection Degree: IP65
  • Installation Style: Wall-mounted
  • Warranty: 5 years
